PMM8218TP Specifications Series Power Modules Part Number PMM8218TP Product Attributes Legacy, Tracking Status Discontinued Isolation Non-Isolated Regulation Regulated Input Voltage (min) 8V Input Voltage (max) 14V Output Voltage (min) 0.8V Output Voltage (max) 5.5V Output Power 275W Output Current 50A Paralleling None Series PMM Typical Efficiency 96% Length 52mm Width 26.7mm Height 9.07mm Package Type Open Frame Mounting Type TH Application Telecom, Industrial Images are for illustrative purposes only. Resources Datasheets PMM8000 Product Discontinuation Notices Product Discontinuation Notice – PMH, PMJ and PMM series 09/28/2022 Technical Papers TP018: Safety Requirements TP020: Verification & Qualification Considerations Safety Product Notice – UL62368 upgrade Application Notes AN319: Repair & Rework Recommendations Design Notes DN002: Power Supply Reliability Aspects DN024: Power Modules Basics DN023: Architecture Selection DN022: Output Ripple & Noise Measurement DN021: Enabling with RC Pin DN028: Thermal Characterization in Sealed Applications DN019: Thermal Characterization DN014: Voltage Monitoring DN013: OnOff Control with RC Pin DN012: Ouput Overvoltage Protection DN026: Start-Up with External Voltage on Output DN007: Output Voltage Alarm Circuit DN025: Forced Air Cooling at High Altitude DN029: Conducted EMC Filters DN027: Test Methods Brochures POLA Cross Reference 2019 Telecom DC/DC Solutions 2026 Data Center DC/DC Solutions 2026 POLA Cross Reference Flyer: Flex Power Modules’ capabilities Industrial and Railway DC/DC Solutions 2025 Environmental REACH Statement of Compliance RoHS Statement of Compliance Stock
