PMH4518TP Specifications Series Power Modules Part Number PMH4518TP Product Attributes Legacy, Tracking Status Discontinued Isolation Non-Isolated Regulation Regulated Input Voltage (min) 2.95V Input Voltage (max) 3.65V Output Voltage (min) 0.8V Output Voltage (max) 2.5V Output Power 55W Output Current 22A Paralleling None Series PMH Typical Efficiency 93% Length 38.1mm Width 22.1mm Height 9mm Package Type Open Frame Mounting Type TH Application Telecom, Industrial Images are for illustrative purposes only. Resources Datasheets PMH4000 Product Discontinuation Notices Product Discontinuation Notice – PMH, PMJ and PMM series 09/28/2022 Technical Papers TP018: Safety Requirements TP020: Verification & Qualification Considerations Safety Product Notice – UL62368 upgrade Application Notes AN319: Repair & Rework Recommendations Design Notes DN022: Output Ripple & Noise Measurement DN021: Enabling with RC Pin DN028: Thermal Characterization in Sealed Applications DN019: Thermal Characterization DN014: Voltage Monitoring DN013: OnOff Control with RC Pin DN012: Ouput Overvoltage Protection DN026: Start-Up with External Voltage on Output DN007: Output Voltage Alarm Circuit DN025: Forced Air Cooling at High Altitude DN002: Power Supply Reliability Aspects DN024: Power Modules Basics DN023: Architecture Selection DN029: Conducted EMC Filters DN027: Test Methods Brochures POLA Cross Reference 2019 Telecom DC/DC Solutions 2026 Data Center DC/DC Solutions 2026 POLA Cross Reference Flyer: Flex Power Modules’ capabilities Industrial and Railway DC/DC Solutions 2025 Environmental REACH Statement of Compliance RoHS Statement of Compliance Stock
